Serie 3 > Modelos de Placa Giratoria y Fija
Hasta 400 lbs
Estas son las Rodajas mas usuales y son muy prácticas fabricadas en Colson, con Platos fijos y giratorios. Sus aplicaciones son muy variadas, diseñadas para trabajos de ligeros a semipesados e institucionales. Para muebles ligeros en la Industria, Hospitales, Hoteles, Escuelas, Maquiladoras, etcétera. En medidas desde 3" hasta 6" de diámetro y 1-1/2" de ancho con capacidades desde 250 hasta 400 libras cada una. Disponibles con una amplia variedad de ruedas como Polipropileno, Performa Plana y Tipo Balón,
Poliuretano HiTech, Acero, Fenólica, Hule Suave, etcétera. Su doble hilera de balines le agrega fuerza y durabilidad.
Características
- Acabado Galvanizado para una mejor apariencia y durabilidad.
- Doble hilera de baleros en giro para mejor desempeño y resistencia.
- Eje de rueda de 3/8".Base con remache permanente para mayor duración.
- Con arandelas reforzadas en las pistas superiores e inferiores para mayor seguridad.
- Baleros con orificio para lubricación interna.
- Grasa "Colson 45" multi-temperatura.
Opciones de Freno
Freno Lateral - Disponible en todos los modelos Giratorios. Instalable en Campo (Especifique BRK1).
Bases
Avaladas por NSF para todos usos.
Pista de Balines protectora de impurezas. (Especifique DC1).
Guarda-hilos disponibles, no aplicables con frenos (Especifique TG1 para metal, TG2 para plástico).
| Opciones de eje. | |
|
AX1 Eje con Grasera. |
NT1 Tuerca gruesa con Candado. |
|
AX2 Eje Solido. |
NT2 Tuerca delgada de seguridad. |
Selección de rueda
Series 3 a 5 Ruedas de Neopreno Performa
Serie 3 a 5 Ruedas Performa Conductivas
Ruedas de Poliuretano HiTech
Series 3 a 5 Ruedas de Poliolefino
Ruedas Maxim
Serie 3 > Modelos de Placa Giratoria y Fija > Hasta 400 lbs
| No. de Modelo | Descripcion de Rodaja | Diametro de Rueda | Ancho de Rueda | Capacidad por Rodaja | Rueda | Balero | Altura de Carga | Radio de Giro | Peso |
| 3.00317.441 | Serie 3 : Top Plate Swivel | 3 | 1-1/2 | 250 | Performa Rubber (Flat/Grey) | Delrin | 4-1/2 | 3-1/8 | 3 |
| 3.00317.449 | Serie 3 : Top Plate Swivel | 3 | 1-1/2 | 250 | Performa Rubber (Flat/Grey) | Roller | 4-1/2 | 3-1/8 | 3 |
| 3.00317.801 | Serie 3 : Top Plate Swivel | 3 | 1-1/2 | 300 | Polyolefin | Delrin | 4-1/2 | 3-1/8 | 2-3/4 |
| 3.00317.809 | Serie 3 : Top Plate Swivel | 3 | 1-1/2 | 300 | Polyolefin | Roller | 4-1/2 | 3-1/8 | 2-3/4 |
| 3.00317.901 | Serie 3 : Top Plate Swivel | 3 | 1-1/2 | 300 | Polyurethane HI-TECH | Delrin | 4-1/2 | 3-1/8 | 3 |
| 3.00317.909 | Serie 3 : Top Plate Swivel | 3 | 1-1/2 | 300 | Polyurethane HI-TECH | Roller | 4-1/2 | 3-1/8 | 3 |
| 3.00317.301 | Serie 3 : Top Plate Swivel | 3 | 1-1/2 | 400 | Phenolic | Delrin | 4-1/2 | 3-1/8 | 2-3/4 |
| 3.00317.305 | Serie 3 : Top Plate Swivel | 3 | 1-1/2 | 400 | Phenolic | Ball | 4-1/2 | 3-1/8 | 2-3/4 |
| 3.00317.309 | Serie 3 : Top Plate Swivel | 3 | 1-1/2 | 400 | Phenolic | Roller | 4-1/2 | 3-1/8 | 2-3/4 |
| 3.00317.101 | Serie 3 : Top Plate Swivel & Rigid | 3 | 1-1/2 | 400 | Cast Iron | Delrin | 4-1/2 | 3-1/8 | 4-1/4 |
| 3.00317.109 | Serie 3 : Top Plate Swivel | 3 | 1-1/2 | 400 | Cast Iron | Roller | 4-1/2 | 3-1/8 | 4-1/4 |
| 3.00417.449 COND | Serie 3 : Top Plate Swivel | 4 | 1-1/2 | 255 | Performa Rubber (Conductive Flat) | Roller | 5-3/8 | 3-5/8 | 3-1/2 |
| 3.00417.441 | Serie 3 : Top Plate Swivel | 4 | 1-1/2 | 325 | Performa Rubber (Flat/Grey) | Delrin | 5-3/8 | 3-5/8 | 3-1/2 |
| 3.00417.449 | Serie 3 : Top Plate Swivel | 4 | 1-1/2 | 325 | Performa Rubber (Flat/Grey) | Roller | 5-3/8 | 3-5/8 | 3-1/2 |
| 3.00417.801 | Serie 3 : Top Plate Swivel | 4 | 1-1/2 | 375 | Polyolefin | Delrin | 5-3/8 | 3-5/8 | 3 |
| 3.00417.809 | Serie 3 : Top Plate Swivel | 4 | 1-1/2 | 375 | Polyolefin | Roller | 5-3/8 | 3-5/8 | 3 |
| 3.00417.501 | Serie 3 : Top Plate Swivel | 4 | 1-1/2 | 400 | Maxim | Delrin | 5-3/8 | 3-5/8 | 3-1/4 |
| 3.00417.504 | Serie 3 : Top Plate Swivel | 4 | 1-1/2 | 400 | Maxim | Bronze | 5-3/8 | 3-5/8 | 3-1/4 |
| 3.00417.509 | Serie 3 : Top Plate Swivel | 4 | 1-1/2 | 400 | Maxim | Roller | 5-3/8 | 3-5/8 | 3-1/4 |
| 3.00417.901 | Serie 3 : Top Plate Swivel | 4 | 1-1/2 | 400 | Polyurethane HI-TECH | Delrin | 5-3/8 | 3-5/8 | 3-1/4 |
| 3.00417.909 | Serie 3 : Top Plate Swivel | 4 | 1-1/2 | 400 | Polyurethane HI-TECH | Roller | 5-3/8 | 3-5/8 | 3-1/4 |
| 3.00417.301 | Serie 3 : Top Plate Swivel | 4 | 1-1/2 | 400 | Phenolic Delrin | 5-3/8 | 3-5/8 | 3-1/2 | |
| 3.00417.305 | Serie 3 : Top Plate Swivel | 4 | 1-1/2 | 400 | Phenolic Ball | 5-3/8 | 3-5/8 | 3-1/2 | |
| 3.00417.309 | Serie 3 : Top Plate Swivel | 4 | 1-1/2 | 400 | Phenolic Roller | 5-3/8 | 3-5/8 | 3-1/4 | |
| 3.00417.101 | Serie 3 : Top Plate Swivel | 4 | 1-1/2 | 400 | Cast Iron | Delrin | 5-3/8 | 3-5/8 | 4-1/2 |
| 3.00417.109 | Serie 3 : Top Plate Swivel | 4 | 1-1/2 | 400 | Cast Iron | Roller | 5-3/8 | 3-5/8 | 4-1/2 |
| 3.00517.449 COND | Serie 3 : Top Plate Swivel | 5 | 1-1/2 | 280 | Performa Rubber (Conductive Flat) | Roller | 6-3/8 | 4-1/8 | 3-1/2 |
| 3.00517.441 | Serie 3 : Top Plate Swivel | 5 | 1-1/2 | 350 | Performa Rubber (Flat/Grey) | Delrin | 6-3/8 | 4-1/8 | 3-1/2 |
| 3.00517.449 | Serie 3 : Top Plate Swivel | 5 | 1-1/2 | 350 | Performa Rubber (Flat/Grey) | Roller | 6-3/8 | 4-1/8 | 3-1/2 |
| 3.00517.801 | Serie 3 : Top Plate Swivel | 5 | 1-1/2 | 400 | Polyolefin | Delrin | 6-3/8 | 4-1/8 | 2-3/4 |
| 3.00517.809 | Serie 3 : Top Plate Swivel | 5 | 1-1/2 | 400 | Polyolefin | Roller | 6-3/8 | 4-1/8 | 2-3/4 |
| 3.00517.901 | Serie 3 : Top Plate Swivel | 5 | 1-1/2 | 400 | Polyurethane HI-TECH | Delrin | 6-3/8 | 4-1/8 | 3-1/2 |
| 3.00517.909 | Serie 3 : Top Plate Swivel | 5 | 1-1/2 | 400 | Polyurethane HI-TECH | Roller | 6-3/8 | 4-1/8 | 3-1/2 |
| 3.00517.301 | Serie 3 : Top Plate Swivel | 5 | 1-1/2 | 400 | Phenolic | Delrin | 6-3/8 | 4-1/8 | 3 |
| 3.00517.305 | Serie 3 : Top Plate Swivel | 5 | 1-1/2 | 400 | Phenolic | Ball | 6-3/8 | 4-1/8 | 3 |
| 3.00517.309 | Serie 3 : Top Plate Swivel | 5 | 1-1/2 | 400 | Phenolic | Roller | 6-3/8 | 4-1/8 | 3-1/4 |
| 3.00517.101 | Serie 3 : Top Plate Swivel | 5 | 1-1/2 | 400 | Cast Iron | Delrin | 6-3/8 | 4-1/8 | 5 |
| 3.00517.109 | Serie 3 : Top Plate Swivel | 5 | 1-1/2 | 400 | Cast Iron | Roller | 6-3/8 | 4-1/8 | 5 |
| 3.00617.449 COND | Serie 3 : Top Plate Swivel | 6 | 1-1/2 | 300 | Performa Rubber (Conductive Flat) | Roller | 7-3/8 | 4-5/8 | 3-3/4 |
| 3.00617.441 | Serie 3 : Top Plate Swivel | 6 | 1-1/2 | 375 | Performa Rubber (Flat/Grey) | Delrin | 7-3/8 | 4-5/8 | 3-3/4 |
| 3.00617.449 | Serie 3 : Top Plate Swivel | 6 | 1-1/2 | 375 | Performa Rubber (Flat/Grey) | Roller | 7-3/8 | 4-5/8 | 3-3/4 |
| 3.00617.801 | Serie 3 : Top Plate Swivel | 6 | 1-1/2 | 400 | Polyolefin | Delrin | 7-3/8 | 4-5/8 | 3 |
| 3.00617.809 | Serie 3 : Top Plate Swivel | 6 | 1-1/2 | 400 | Polyolefin | Roller | 7-3/8 | 4-5/8 | 3 |
| 3.00617.901 | Serie 3 : Top Plate Swivel | 6 | 1-1/2 | 400 | Polyurethane HI-TECH | Delrin | 7-3/8 | 4-5/8 | 3-3/4 |
| 3.00617.909 | Serie 3 : Top Plate Swivel | 6 | 1-1/2 | 400 | Polyurethane HI-TECH | Roller | 7-3/8 | 4-5/8 | 3-3/4 |
| 3.00617.301 | Serie 3 : Top Plate Swivel | 6 | 1-1/2 | 400 | Phenolic | Delrin | 7-3/8 | 4-5/8 | 3-1/2 |
| 3.00617.305 | Serie 3 : Top Plate Swivel | 6 | 1-1/2 | 400 | Phenolic | Ball | 7-3/8 | 4-5/8 | 3-1/2 |
| 3.00617.309 | Serie 3 : Top Plate Swivel | 6 | 1-1/2 | 400 | Phenolic | Roller | 7-3/8 | 4-5/8 | 3-3/4 |
| 3.00617.101 | Serie 3 : Top Plate Swivel | 6 | 1-1/2 | 400 | Cast Iron | Delrin | 7-3/8 | 4-5/8 | 6 |
| 3.00617.109 | Serie 3 : Top Plate Swivel | 6 | 1-1/2 | 400 | Cast Iron | Roller | 7-3/8 | 4-5/8 | 6 |
| 3.00308.441 | Serie 3 : Top Plate Rigid | 3 | 1-1/2 | 250 | Performa Rubber (Flat/Grey) | Delrin | 4-1/2 | 3-1/8 | 3 |
| 3.00308.449 | Serie 3 : Top Plate Rigid | 3 | 1-1/2 | 250 | Performa Rubber (Flat/Grey) | Roller | 4-1/2 | 3-1/8 | 3 |
| 3.00308.801 | Serie 3 : Top Plate Rigid | 3 | 1-1/2 | 300 | Polyolefin | Delrin | 4-1/2 | 3-1/8 | 2-3/4 |
| 3.00308.809 | Serie 3 : Top Plate Rigid | 3 | 1-1/2 | 300 | Polyolefin | Roller | 4-1/2 | 3-1/8 | 2-3/4 |
| 3.00308.901 | Serie 3 : Top Plate Rigid | 3 | 1-1/2 | 300 | Polyurethane HI-TECH | Delrin | 4-1/2 | 3-1/8 | 3 |
| 3.00308.909 | Serie 3 : Top Plate Rigid | 3 | 1-1/2 | 300 | Polyurethane HI-TECH | Roller | 4-1/2 | 3-1/8 | 3 |
| 3.00308.301 | Serie 3 : Top Plate Rigid | 3 | 1-1/2 | 400 | Phenolic | Delrin | 4-1/2 | 3-1/8 | 2-3/4 |
| 3.00308.305 | Serie 3 : Top Plate Rigid | 3 | 1-1/2 | 400 | Phenolic | Ball | 4-1/2 | 3-1/8 | 2-3/4 |
| 3.00308.309 | Serie 3 : Top Plate Rigid | 3 | 1-1/2 | 400 | Phenolic | Roller | 4-1/2 | 3-1/8 | 2-3/4 |
| 3.00308.109 | Serie 3 : Top Plate Rigid | 3 | 1-1/2 | 400 | Cast Iron | Roller | 4-1/2 | 3-1/8 | 4-1/4 |
| 3.00408.449 COND | Serie 3 : Top Plate Rigid | 4 | 1-1/2 | 255 | Performa Rubber (Conductive Flat) | Roller | 5-3/8 | 3-5/8 | 3-1/2 |
| 3.00408.441 | Serie 3 : Top Plate Rigid | 4 | 1-1/2 | 325 | Performa Rubber (Flat/Grey) | Delrin | 5-3/8 | 3-5/8 | 3-1/2 |
| 3.00408.449 | Serie 3 : Top Plate Rigid | 4 | 1-1/2 | 325 | Performa Rubber (Flat/Grey) | Roller | 5-3/8 | 3-5/8 | 3-1/2 |
| 3.00408.801 | Serie 3 : Top Plate Rigid | 4 | 1-1/2 | 375 | Polyolefin | Delrin | 5-3/8 | 3-5/8 | 3 |
| 3.00408.809 | Serie 3 : Top Plate Rigid | 4 | 1-1/2 | 375 | Polyolefin | Roller | 5-3/8 | 3-5/8 | 3 |
| 3.00408.501 | Serie 3 : Top Plate Rigid | 4 | 1-1/2 | 400 | Maxim Delrin | 5-3/8 | 3-5/8 | 3-1/4 | |
| 3.00408.504 | Serie 3 : Top Plate Rigid | 4 | 1-1/2 | 400 | Maxim Bronze | 5-3/8 | 3-5/8 | 3-1/4 | |
| 3.00408.501 | Serie 3 : Top Plate Rigid | 4 | 1-1/2 | 400 | Maxim Roller | 5-3/8 | 3-5/8 | 3-1/4 | |
| 3.00408.901 | Serie 3 : Top Plate Rigid | 4 | 1-1/2 | 400 | Polyurethane HI-TECH | Delrin | 5-3/8 | 3-5/8 | 3-1/4 |
| 3.00408.909 | Serie 3 : Top Plate Rigid | 4 | 1-1/2 | 400 | Polyurethane HI-TECH | Roller | 5-3/8 | 3-5/8 | 3-1/4 |
| 3.00408.301 | Serie 3 : Top Plate Rigid | 4 | 1-1/2 | 400 | Phenolic | Delrin | 5-3/8 | 3-5/8 | 3-1/2 |
| 3.00408.305 | Serie 3 : Top Plate Rigid | 4 | 1-1/2 | 400 | Phenolic | Ball | 5-3/8 | 3-5/8 | 3-1/2 |
| 3.00408.309 | Serie 3 : Top Plate Rigid | 4 | 1-1/2 | 400 | Phenolic | Roller | 5-3/8 | 3-5/8 | 3-1/4 |
| 3.00408.101 | Serie 3 : Top Plate Rigid | 4 | 1-1/2 | 400 | Cast Iron | Delrin | 5-3/8 | 3-5/8 | 4-1/2 |
| 3.00408.109 | Serie 3 : Top Plate Rigid | 4 | 1-1/2 | 400 | Cast Iron | Roller | 5-3/8 | 3-5/8 | 4-1/2 |
| 3.00508.449 COND | Serie 3 : Top Plate Rigid | 5 | 1-1/2 | 280 | Performa Rubber (Conductive Flat) | Roller | 6-3/8 | 4-1/8 | 3-1/2 |
| 3.00508.441 | Serie 3 : Top Plate Rigid | 5 | 1-1/2 | 350 | Performa Rubber (Flat/Grey) | Delrin | 6-3/8 | 4-1/8 | 3-1/2 |
| 3.00508.449 | Serie 3 : Top Plate Rigid | 5 | 1-1/2 | 350 | Performa Rubber (Flat/Grey) | Roller | 6-3/8 | 4-1/8 | 3-1/2 |
| 3.00508.801 | Serie 3 : Top Plate Rigid | 5 | 1-1/2 | 400 | Polyolefin | Delrin | 6-3/8 | 4-1/8 | 2-3/4 |
| 3.00508.809 | Serie 3 : Top Plate Rigid | 5 | 1-1/2 | 400 | Polyolefin | Roller | 6-3/8 | 4-1/8 | 2-3/4 |
| 3.00508.901 | Serie 3 : Top Plate Rigid | 5 | 1-1/2 | 400 | Polyurethane HI-TECH | Delrin | 6-3/8 | 4-1/8 | 3-1/2 |
| 3.00508.909 | Serie 3 : Top Plate Rigid | 5 | 1-1/2 | 400 | Polyurethane HI-TECH | Roller | 6-3/8 | 4-1/8 | 3-1/2 |
| 3.00508.301 | Serie 3 : Top Plate Rigid | 5 | 1-1/2 | 400 | Phenolic | Delrin | 6-3/8 | 4-1/8 | 3 |
| 3.00508.305 | Serie 3 : Top Plate Rigid | 5 | 1-1/2 | 400 | Phenolic | Ball | 6-3/8 | 4-1/8 | 3 |
| 3.00508.309 | Serie 3 : Top Plate Rigid | 5 | 1-1/2 | 400 | Phenolic | Roller | 6-3/8 | 4-1/8 | 3-1/4 |
| 3.00508.101 | Serie 3 : Top Plate Rigid | 5 | 1-1/2 | 400 | Cast Iron | Delrin | 6-3/8 | 4-1/8 | 5 |
| 3.00508.109 | Serie 3 : Top Plate Rigid | 5 | 1-1/2 | 400 | Cast Iron | Roller | 6-3/8 | 4-1/8 | 5 |
| 3.00608.449 COND | Serie 3 : Top Plate Rigid | 6 | 1-1/2 | 300 | Performa Rubber (Conductive Flat) | Roller | 7-3/8 | 4-5/8 | 3-3/4 |
| 3.00608.441 | Serie 3 : Top Plate Rigid | 6 | 1-1/2 | 375 | Performa Rubber (Flat/Grey) | Delrin | 7-3/8 | 4-5/8 | 3-3/4 |
| 3.00608.449 | Serie 3 : Top Plate Rigid | 6 | 1-1/2 | 375 | Performa Rubber (Flat/Grey) | Roller | 7-3/8 | 4-5/8 | 3-3/4 |
| 3.00608.801 | Serie 3 : Top Plate Rigid | 6 | 1-1/2 | 400 | Polyolefin | Delrin | 7-3/8 | 4-5/8 | 3 |
| 3.00608.809 | Serie 3 : Top Plate Rigid | 6 | 1-1/2 | 400 | Polyolefin | Roller | 7-3/8 | 4-5/8 | 3 |
| 3.00608.901 | Serie 3 : Top Plate Rigid | 6 | 1-1/2 | 400 | Polyurethane HI-TECH | Delrin | 7-3/8 | 4-5/8 | 3-3/4 |
| 3.00608.909 | Serie 3 : Top Plate Rigid | 6 | 1-1/2 | 400 | Polyurethane HI-TECH | Roller | 7-3/8 | 4-5/8 | 3-3/4 |
| 3.00608.301 | Serie 3 : Top Plate Rigid | 6 | 1-1/2 | 400 | Phenolic | Delrin | 7-3/8 | 4-5/8 | 3-1/2 |
| 3.00608.305 | Serie 3 : Top Plate Rigid | 6 | 1-1/2 | 400 | Phenolic | Ball | 7-3/8 | 4-5/8 | 3-1/2 |
| 3.00608.309 | Serie 3 : Top Plate Rigid | 6 | 1-1/2 | 400 | Phenolic | Roller | 7-3/8 | 4-5/8 | 3-3/4 |
| 3.00608.101 | Serie 3 : Top Plate Rigid | 6 | 1-1/2 | 400 | Cast Iron | Delrin | 7-3/8 | 4-5/8 | 6 |
| 3.00608.109 | Serie 3 : Top Plate Rigid | 6 | 1-1/2 | 400 | Cast Iron | Roller | 7-3/8 | 4-5/8 | 6 |
